MIC Series

MIC Series

MIC Series

Product Code Product Description Current Value Voltage Value Withstand Voltage Body Material Operating Temperature Technical Drawing
2 Pin
8100-2P-M 2 Pin Cable Solder Type Mini Female Mic Connector 5A 250V - Copper (Silver Plated / Gold) -
2 Pin
8000-2B-M 2 Pin Cable Soldered Type Mini Male Mic Connector 5A 250V - Copper (Silver Plated / Gold) -
2 Pin
8000-2A-M Mic Male to Chassis Type Cable Soldered Type Mini 5A 250V - Steel-ZINC Plated/Brass -
2 Pin
8000-02A 2 Pin Chassis Type Male Mic Connector 10A - 1500V / AC /munite Steel-ZINC Plated/Brass -
2 Pin
8000-02C 2 Pin Chassis Mount Flange Type Male Mic Connector 10A - 1500V / AC /munite Steel-ZINC Plated/Brass -
2 Pin
8000-02B 2 Pin Cable Type Male Mic Connector 10A - 1500V / AC /munite Steel-ZINC Plated/Brass -
2 Pin
8100-02P 2 Pin Cable Type Female Mic Connector 10A - 1500V / AC /munite Steel-ZINC Plated/Brass -
3 Pin
8100-3P-M 3 Pin Cable Solder Type Mini Female Mic Connector 5A 250V - Copper (Silver Plated / Gold) -
3 Pin
8000-3B-M 3 Pin Cable Soldered Type Mini Male Mic Connector 5A 250V - Copper (Silver Plated / Gold) -
3 Pin
8000-3A-M 3 Pin Mic Male Chassis type Cable Soldered Type Mini 5A 250V - Steel-ZINC Plated/Brass -
3 Pin
8000-03A 3 Pin Chassis Type Male Mic Connector 10A - 1500V / AC /munite Steel-ZINC Plated/Brass -
10 Pin
8000-03C 3 Pin Chassis Mount Flange Type Male Mic Connector 10A - 1500V / AC /munite Steel-ZINC Plated/Brass -
3 Pin
8000-03B 3 Pin Cable Type Male Mic Connector 10A - 1500V / AC /munite Steel-ZINC Plated/Brass -
3 Pin
8100-03P 3 Pin Cable Type Female Mic Connector 10A - 1500V / AC /munite Steel-ZINC Plated/Brass -
4 Pin
8100-4P-M 4 Pin Cable Solder Type Mini Female Mic Connector 5A 250V - Copper (Silver Plated / Gold) -
4 Pin
8000-4B-M 4 Pin Cable Soldered Type Mini Male Mic Connector 5A 250V - Copper (Silver Plated / Gold) -
4 Pin
8000-4A-M 4 Pin Mic Male Chassis type Cable Soldered Type Mini 5A 250V - Steel-ZINC Plated/Brass -
4 Pin
8000-04A 4 Pin Chassis Type Male Mic Connector 10A - 1500V / AC /munite Steel-ZINC Plated/Brass -
4 Pin
8000-04C 4 Pin Chassis Mount Flange Type Male Mic Connector 10A - 1500V / AC /munite Steel-ZINC Plated/Brass -
4 Pin
8000-04B 4 Pin Cable Type Male Mic Connector 10A - 1500V / AC /munite Steel-ZINC Plated/Brass -
4 Pin
8100-04P 4 Pin Cable Type Female Mic Connector 10A - 1500V / AC /munite Steel-ZINC Plated/Brass -
5 Pin
8100-5P-M 5 Pin Cable Solder Type Mini Female Mic Connector 5A 250V - Copper (Silver Plated / Gold) -
5 Pin
8000-5B-M 5 Pin Cable Soldered Type Mini Male Mic Connector 5A 250V - Copper (Silver Plated / Gold) -
5 Pin
8000-5A-M 5 Pin Mic Male to Chassis type Cable Soldered Type Mini 5A 250V - Steel-ZINC Plated/Brass -
5 Pin
8000-05A 5 Pin Chassis Type Male Mic Connector 10A - 1500V / AC /munite Steel-ZINC Plated/Brass -
5 Pin
8000-05C 5 Pin Chassis Mount Flange Type Male Mic Connector 10A - 1500V / AC /munite Steel-ZINC Plated/Brass -
5 Pin
8000-05B 5 Pin Cable Type Male Mic Connector 10A - 1500V / AC /munite Steel-ZINC Plated/Brass -
5 Pin
8100-05P 5 Pin Cable Type Female Mic Connector 10A - 1500V / AC /munite Steel-ZINC Plated/Brass -
6 Pin
8100-6P-M 6 Pin Cable Solder Type Mini Female Mic Connector 5A 250V - Copper (Silver Plated / Gold) -
6 Pin
8000-6B-M 6 Pin Cable Soldered Type Mini Male Mic Connector 5A 250V - Copper (Silver Plated / Gold) -
6 Pin
8000-6A-M 6 Pin Mic Male to Chassis type Cable Soldered Type Mini 5A 250V - Steel-ZINC Plated/Brass -
6 Pin
8000-06A 6 Pin Chassis Type Male Mic Connector 10A - 1500V / AC /munite ABS + PVC / Nickel-PA6 -
6 Pin
8000-06C 6 Pin Chassis Mount Flange Type Male Mic Connector 10A - 1500V / AC /munite Steel-ZINC Plated/Brass -
6 Pin
8000-06B 6 Pin Cable Type Male Mic Connector 10A - 1500V / AC /munite ABS + PVC / Nickel-PA6 -
6 Pin
8100-06P 6 Pin Cable Type Female Mic Connector 10A - 1500V / AC /munite Steel-ZINC Plated/Brass -
7 Pin
8100-7P-M 7 Pin Cable Solder Type Mini Female Mic Connector 5A 250V - ABS + PVC / Nickel-PA6 -
7 Pin
8000-7B-M 7 Pin Cable Soldered Type Mini Male Mic Connector 5A 250V - Steel-ZINC Plated/Brass -
7 Pin
8000-7A-M 7 Pin Mic Male to Chassis type Cable Soldered Type Mini 5A 250V - ABS + PVC / Nickel-PA6 -
7 Pin
8000-07A 7 Pin Chassis Type Male Mic Connector 10A - 1500V / AC /munite Steel-ZINC Plated/Brass -
7 Pin
8000-07C 7 Pin Chassis Mount Flange Type Male Mic Connector 10A - 1500V / AC /munite - -
7 Pin
8000-07B 7 Pin Cable Type Male Mic Connector 10A - 1500V / AC /munite Steel-ZINC Plated/Brass -
7 Pin
8100-07P 7 Pin Cable Type Female Mic Connector 10A - 1500V / AC /munite Steel-ZINC Plated/Brass -
8 Pin
8000-8B-M 8 Pin Cable Soldered Type Mini Female Mic Connector 5A 250VAC - Steel-ZINC Plated/Brass -
8 Pin
8000-8B-M 8 Pin Cable Soldered Type Mini Male Mic Connector 5A 250VAC - Steel-ZINC Plated/Brass -
8 Pin
8000-8A-M 8 Pin Mic Male to Chassis type Cable Soldered Type Mini 5A 250VAC - Steel-ZINC Plated/Brass
8 Pin
8000-08A 8 Pin Chassis Type Male Mic Connector 10A - 1500V / AC /munite Steel-ZINC Plated/Brass -
8 Pin
8000-08C 8 Pin Chassis Mount Flange Type Male Mic Connector 10A - 1500V / AC /munite Steel-ZINC Plated/Brass -
8 Pin
8000-08B 8 Pin Cable Type Male Mic Connector 10A - 1500V / AC /munite Steel-ZINC Plated/Brass -
8 Pin
8100-08P 8 Pin Cable Type Female Mic Connector 10A - 1500V / AC /munite Steel-ZINC Plated/Brass -
