M12 3 Pin Cırcular Female Connector

M12 3 Pin Cırcular Female Connector

Material

Housing PBT UL94V-0; Color:Black
Contact Brass
Nut Brass
O-Ring                  Epdm;Color:Black

Finish

Under Plate Nickel
Contact 10 Micro Inches Min. Gold Plating.
Nut Nickel Plated 60u''~100u'' Over All.

Technicial Specifications

Circuits 3 Pin
Current Rating 5A
Voltage Rating 125V
Type Female
IP Rating IP67
Temperature Range -25°C # +85°C
