Product Code:S-08
| Standard | IEC 61076-2-101/IEC 60947-5-2 |
|---|---|
| Housing | PBT UL94V-0; Color:Black |
| Contact | Phosphor Bronze |
| Nut | Brass |
| O-Ring | NBR ; Color:Black |
| Contact | 10 Micro Inches Min. Gold Plating. |
| Solder Area | Gold Flash. |
| Under Plate | Nickel |
| Nut | Nickel Plated 60u''~100u'' Over All. |
| Rated Current | 5A |
| Voltage | 125V |
| IP Rating | IP67 |
| Protecttion class | IP67 (IEC 60529) |
| Temperature range | -20°C to +85°C |
