TECHNICAL SPECIFICATIONS
• Class E/Category 6 standards compliant
• Molded RJ45 connectors
• Electrically compliant beyond 250 Mhz
• Connector connection material; 1,27μm(50 μ-inc) gold plated over 2,54μm(100 μ-inc) Nickel
• 6 standard colours (Grey, White, Blue, Red, Yellow, Green, Orange)
• 9 standart lengths (0,5m, 1m, 2m, 3m, 5m, 7m, 10m, 15m, 20m), other lengths are available upon request.
• Carefully constructed and tested, to keep Near End Crosstalk (NEXT) well within acceptable limits
• Colored hoods for departmental color coding
• Constructed with top quality components
• RoHS compliant 2002/95/EC
• High quality 23/24/AWG Solid and stranded copper wire
• Number of Conductors 4 Pair UTP
• Number of insulated conductors 8 twisted per
• Cable jacket type, PVC-Polyvinyl Chloride
• Connector A&B RJ-45 Male, RJ-45 Male
• Both of RJ-45 connectors available IEC 60603-7-41 terminated
APLİCATİON
• Designed for use with Megabit&Gigabit networks
• Patches from hub to distribution panel
• Connects workstation to wall outlet
• 10 Base-T,100 Base-TX,1000Base-TX
• Token Ring 4-16 Mbit, 155-622 Mbit ATM
• ISDN etc..
The production is made in any desired length
